LB-48-800-CC LB-Series Constant Current DC Load Bank
Overview
The Eagle Eye Power Solutions LB-48-800-CC Constant Current DC Load Bank from Eagle Eye Power Solutions is engineered for controlled, high-current battery discharge testing across a wide range of DC applications.
Designed for simplicity and performance, the LB-Series maintains precise constant current discharge without requiring operator adjustments during the test. Intelligent internal control automatically stabilizes the discharge current, ensuring accurate and repeatable battery capacity verification.
The LB-48-800-CC is ideal for acceptance testing, maintenance testing, performance validation, and capacity verification of stationary battery systems. Built-in safety protections include overheating shutdown, reverse polarity detection, abnormal disconnection alarms, and automatic post-test cooling operation.
With auto-sensing voltage capability and compatibility with a broad range of battery chemistries including VRLA, VLA, and NiCad, the LB-Series is widely used in utilities, telecommunications, UPS systems, motive power, transportation, CATV, and industrial environments.
Optional configurations allow for programmable load steps, cell voltage monitoring (CCS models), and advanced reporting software integration.
Features
- High-current constant current DC discharge load
- Designed for battery capacity, acceptance, and maintenance testing
- Auto-sensing voltage range from 5 – 600V
- LED display for voltage, current, and test time
- Four auto-stop discharge conditions: Test Time, End Voltage, Exceeded Capacity, and Cell Voltage (CCS models)
- Overheat, reverse polarity, and abnormal disconnection protection
- Automatic fan operation after discharge for enhanced thermal protection
- Saves previously used test parameters after power down
- Optional programmable load steps and cell monitoring packages
- Portable and industrial-grade construction
Specifications
| Model: | LB-48-800-CC |
| Discharge Voltage Range: | 5 – 600V (Auto-Sensing) |
| Discharge Current Range: | 1 – 2000A (Model Rated for High Current Applications) |
| Per Cell Voltage Compatibility: | 1 – 12V VRLA, VLA, NiCad and more |
| Accuracy: | Current: ±1% / Voltage: ±1% |
| Resolution: | Current: 0.1A / Voltage: 0.1V |
| Data Transfer: | RS-232, USB |
| Display: | Backlit Numeric LED (CC Model) |
| Operating Temperature: | 0 – 40 °C (32 – 104 °F) |
| Power Requirements: | 110/220 VAC 50/60 Hz |
| Available Sizes: | Small through XXX-Large (varies by configuration) |
Resources & Support
Product Literature
Support Documents
Videos
FAQs
What is the LB-48-800-CC used for?
The LB-48-800-CC is designed for controlled high-current DC battery discharge testing to verify capacity, performance, and system reliability.
Does this unit maintain constant current automatically?
Yes. The LB-Series uses intelligent control technology to maintain constant current discharge throughout the test without manual adjustment.
What industries commonly use the LB-48-800-CC?
This model is widely used in utilities, telecommunications, UPS systems, transportation, motive power, CATV, and industrial DC applications.
What safety protections are included?
The unit includes overheat protection, reverse polarity detection, abnormal disconnection alarms, automatic shutdown, and post-test cooling fan operation.
Can this unit support compliance-related testing?
Yes. The LB-Series is frequently used for acceptance testing, maintenance testing, and compliance-related discharge verification in critical power environments.
