LB-48-200-CC LB Series Constant Current DC Load Bank
Overview
The Eagle Eye Power Solutions LB-48-200-CC Constant Current DC Load Bank from Eagle Eye Power Solutions is engineered for professional battery discharge testing and DC system verification.
Designed for simplicity, portability, and dependable performance, the LB-Series delivers true constant current discharge without requiring operator adjustments during the test. Intelligent internal control maintains stable current throughout the discharge cycle, ensuring accurate capacity verification.
The LB-48-200-CC supports discharge testing for capacity, acceptance, maintenance, and performance validation of DC battery systems. With built-in safety protections including overheating alarms, reverse polarity detection, and abnormal disconnection shutdown, the unit enhances both technician and battery system safety.
With auto-sensing voltage capability and broad current range flexibility, the LB-Series is widely used in utilities, telecommunications, UPS systems, transportation, motive power, CATV, and industrial applications.
Optional configurations allow for programmable load steps, cell voltage monitoring, and advanced reporting software for expanded functionality.
Features
- Constant current DC discharge load with intelligent current regulation
- Designed for battery capacity, acceptance, and maintenance testing
- Auto-sensing discharge voltage range (5 – 600V)
- LED display showing voltage, current, and test time
- Four programmable auto-stop conditions: Test Time, End Voltage, Exceeded Capacity, and Cell Voltage (CCS models)
- Overheat, reverse polarity, and abnormal disconnection protection
- Automatic fan operation after testing for thermal protection
- Stores previously used test parameters after power down
- Optional programmable load steps and cell monitoring packages
- Portable and economical design for field use
Specifications
| Model: | LB-48-200-CC |
| Discharge Voltage Range: | 5 – 600V (Auto-Sensing) |
| Discharge Current Range: | 1 – 2000A |
| Per Cell Voltage Compatibility: | 1 – 12V VRLA, VLA, NiCad and more |
| Accuracy: | Current: ±1% / Voltage: ±1% |
| Resolution: | Current: 0.1A / Voltage: 0.1V |
| Data Transfer: | RS-232, USB |
| Display: | Backlit Numeric LED (CC Model) |
| Operating Temperature: | 0 – 40 °C (32 – 104 °F) |
| Power Requirements: | 110/220 VAC 50/60 Hz |
| Available Sizes: | Small, Medium, Large, X-Large, XX-Large, XXX-Large |
| Weight: | Varies by model size (22 kg – 300 kg) |
Resources & Support
Product Literature
Support Documents
Videos
FAQs
What is the LB-48-200-CC used for?
The LB-48-200-CC is used for controlled constant current discharge testing of DC battery systems to verify capacity, performance, and system reliability.
Does this unit maintain constant current automatically?
Yes. The LB-Series uses intelligent control technology to maintain constant current discharge without manual adjustment during testing.
What safety protections are included?
The LB-48-200-CC includes overheat protection, reverse polarity detection, abnormal disconnection alarms, and automatic shutdown functions to protect both operators and battery systems.
Is this suitable for utility and telecommunications applications?
Yes. The LB-Series is widely used in utilities, telecommunications, UPS systems, transportation, CATV, and other industrial DC system applications.
Can parameters be saved between tests?
Yes. The unit retains previously used parameters even after powering off, simplifying repeat testing procedures.
