SLB-48-600 SLB-Series DC Load Bank
Overview
The SLB-48-600 SLB-Series DC Load Bank from Eagle Eye Power Solutions is designed for demanding discharge testing of 48V stationary battery systems, delivering programmable constant-current loads up to 600 amps. Ideal for utility substations, telecom networks, industrial facilities, and data centers, it provides a reliable and defensible method for verifying true battery capacity—the definitive measure of system readiness.
The SLB-48-600 incorporates comprehensive protection features designed to enhance both operator safety and system reliability. Built-in safeguards and automatic shutdown functions help prevent unsafe operating conditions, while optional DAC packages enable per-cell voltage monitoring for deeper diagnostic insight during testing. With wireless communication and compatibility with DataView software, technicians gain real-time visibility into test progress, along with robust data logging and exportable reports for documentation and analysis.
For applications requiring greater discharge capacity, the SLB-48-600 can be connected in parallel with other SLB-Series load banks to increase total current capability. The unit also supports assistant discharge mode, allowing it to operate alongside existing non-SLB load banks. This flexibility enables organizations to expand and modernize their battery testing capabilities without the need to immediately replace legacy equipment.
Features
- 48V System Testing: Designed specifically for 48V DC battery strings.
- Up to 600A Programmable Discharge: Constant-current load testing for accurate capacity verification.
- Automatic Discharge Shutdown: Configurable protection based on time duration, total string voltage, capacity, or individual cell voltage.
- Wireless Remote Monitoring (466 MHz): Safely monitor live discharge tests remotely.
- DataView Software Included: Live monitoring, data logging, and exportable reports to Microsoft Excel.
- Parallel Capability: Connect additional SLB-Series units to increase total discharge current.
- Assistant Discharge Mode: Compatible with existing non-SLB load banks.
- Built-In Circuit Breakers: Overload protection and emergency shutdown capability.
- Optional DAC Package: Real-time per-cell voltage monitoring for 1.2V, 2V, 6V, and 12V cells (custom options available).
- Backlit LCD Display: Clear on-site visibility of test parameters and system status.
Specifications
| Nominal System Voltage: | 48 VDC |
| Discharge Current Range: | 12 – 600A (Single Unit) / Up to 1200A (Parallel with Additional SLB Units) |
| Discharge Voltage Range: | 10 – 576V (Max System Capable) |
| Voltage Steps: | 12V, 24V, 36V, 48V, 80V, 125V, 240V, 380V, 480V |
| Cell Voltage Monitoring (Optional DAC): | Standard: 1.2V, 2V, 6V, 12V / Optional: 3.6V, 4V, Custom Configurations Available |
| Accuracy: | Discharge Current: ±1% / Voltage: 0.5% – 0.8% |
| Resolution: | Current: 0.1A or 0.5% / Voltage: 0.001V |
| Sampling Interval: | 5 Seconds – 1 Minute |
| Data Transfer: | USB, Wireless (466 MHz) |
| Display: | Backlit LCD |
| Operating Environment: | 0 – 40 °C (32 – 104 °F) |
| Power Requirements: | 110/220 VAC 50/60 Hz or DC (From Connected Battery) |
| Dimensions: | Varies by Enclosure Size (Small through XX-Large) |
| Weight: | Varies by Enclosure Size (24 – 122 lbs) |
Resources & Support
Product Literature
Support Documents
Downloads
Videos
FAQs
Why is discharge testing necessary?
Discharge testing is needed to confirm true battery capacity and ensure the system can support required loads during an outage.
Is the SLB-48-600 suitable for NERC compliance testing?
Yes. The programmable constant-current discharge and DataView reporting capabilities support documentation requirements for NERC-related maintenance programs.
Can I increase discharge current beyond 600A?
Yes. The SLB-48-600 can be paralleled with another SLB-Series unit to increase total discharge current capacity.
Does this unit support individual cell monitoring?
Yes. With the optional DAC package, real-time monitoring of individual cell voltages is available for multiple cell configurations.
Can the SLB-48-600 work with my existing load bank?
Yes. The Assistant Discharge feature allows it to operate alongside existing non-SLB load banks, adding monitoring capability and increasing current capacity.
What industries commonly use this model?
The SLB-48-600 is commonly used in utility substations, telecom facilities, data centers, and industrial DC power applications.
