SLB-24/48-600 SLB-Series DC Load Bank
Overview
The SLB-24/48-600 SLB-Series DC Load Bank from Eagle Eye Power Solutions is built to handle rigorous discharge testing of 24V and 48V stationary battery systems, delivering fully programmable constant-current loads up to 600 amps. Designed for use across utilities, telecom infrastructure, industrial operations, and data centers, it provides a precise and repeatable method for confirming true battery capacity and overall system reliability.
Engineered with comprehensive safety features, the unit includes built-in protection circuits and automatic shutdown functionality to help safeguard personnel and equipment. Optional DAC packages allow for detailed per-cell voltage monitoring, while wireless connectivity and integration with DataView software provide real-time test visibility, efficient data collection, and streamlined reporting.
To support higher discharge requirements, the SLB-24/48-600 can be operated in parallel with other SLB-Series load banks to increase total current capacity. Its assistant discharge mode also enables compatibility with existing non-SLB load banks, offering a flexible and cost-effective solution for expanding and upgrading battery testing capabilities without replacing legacy systems.
Features
- 24/48V System Testing: Designed specifically for 24/48V DC battery strings.
- Up to 600A Programmable Discharge: Constant-current load testing for accurate capacity verification.
- Automatic Discharge Shutdown: Configurable protection based on time duration, total string voltage, capacity, or individual cell voltage.
- Wireless Remote Monitoring (466 MHz): Safely monitor live discharge tests remotely.
- DataView Software Included: Live monitoring, data logging, and exportable reports to Microsoft Excel.
- Parallel Capability: Connect additional SLB-Series units to increase total discharge current.
- Assistant Discharge Mode: Compatible with existing non-SLB load banks.
- Built-In Circuit Breakers: Overload protection and emergency shutdown capability.
- Optional DAC Package: Real-time per-cell voltage monitoring for 1.2V, 2V, 6V, and 12V cells (custom options available).
- Backlit LCD Display: Clear on-site visibility of test parameters and system status.
Specifications
| Nominal System Voltage: | 24/48 VDC |
| Discharge Current Range: | 12 – 600A (Single Unit) / Up to 1200A (Parallel with Additional SLB Units) |
| Discharge Voltage Range: | 10 – 576V (Max System Capable) |
| Voltage Steps: | 12V, 24V, 36V, 48V, 80V, 125V, 240V, 380V, 480V |
| Cell Voltage Monitoring (Optional DAC): | Standard: 1.2V, 2V, 6V, 12V / Optional: 3.6V, 4V, Custom Configurations Available |
| Accuracy: | Discharge Current: ±1% / Voltage: 0.5% – 0.8% |
| Resolution: | Current: 0.1A or 0.5% / Voltage: 0.001V |
| Sampling Interval: | 5 Seconds – 1 Minute |
| Data Transfer: | USB, Wireless (466 MHz) |
| Display: | Backlit LCD |
| Operating Environment: | 0 – 40 °C (32 – 104 °F) |
| Power Requirements: | 110/220 VAC 50/60 Hz or DC (From Connected Battery) |
| Dimensions: | Varies by Enclosure Size (Small through XX-Large) |
| Weight: | Varies by Enclosure Size (24 – 122 lbs) |
Resources & Support
Product Literature
Support Documents
Downloads
Videos
FAQs
Why is discharge testing necessary?
Discharge testing is the only accurate method to confirm true battery capacity and ensure the system can support required loads during an outage.
Is the SLB-24/48-600 suitable for NERC compliance testing?
Yes. The programmable constant-current discharge and DataView reporting capabilities support documentation requirements for NERC-related maintenance programs.
Can I increase discharge current beyond 400A?
Yes. The SLB-24/48-600 can be paralleled with another SLB-Series unit to increase total discharge current capacity.
Does this unit support individual cell monitoring?
Yes. With the optional DAC package, real-time monitoring of individual cell voltages is available for multiple cell configurations.
Can the SLB-24/48-600 work with my existing load bank?
Yes. The Assistant Discharge feature allows it to operate alongside existing non-SLB load banks, adding monitoring capability and increasing current capacity.
What industries commonly use this model?
The SLB-24/48-600 is commonly used in utility substations, telecom facilities, data centers, and industrial DC power applications.
