SLB-24/48-200 SLB-Series DC Load Bank
Overview
The SLB-24/48-200 SLB-Series DC Load Bank from Eagle Eye Power Solutions is purpose-built for high-accuracy discharge testing of 24V and 48V stationary battery systems, providing fully programmable constant-current loads up to 200 amps. Engineered for mission-critical environments—including utilities, telecom infrastructure, industrial operations, and data centers—it delivers precise, repeatable capacity testing to validate battery performance with confidence.
Advanced safety features, including integrated protection circuits and automatic shutdown functionality, help safeguard both personnel and equipment during testing. Optional DAC packages enable detailed per-cell voltage monitoring, while wireless communication and seamless integration with DataView software provide real-time visibility, streamlined data acquisition, and comprehensive reporting capabilities.
For expanded testing requirements, the SLB-24/48-200 can be easily paralleled with other SLB-Series load banks to increase total discharge current. Its assistant discharge mode also allows it to operate in conjunction with existing non-SLB load banks, offering a flexible and cost-effective solution for upgrading battery testing programs without the need to replace legacy systems.
Features
- 24/48V System Testing: Designed specifically for 24/48V DC battery strings.
- Up to 200A Programmable Discharge: Constant-current load testing for accurate capacity verification.
- Automatic Discharge Shutdown: Configurable protection based on time duration, total string voltage, capacity, or individual cell voltage.
- Wireless Remote Monitoring (466 MHz): Safely monitor live discharge tests remotely.
- DataView Software Included: Live monitoring, data logging, and exportable reports to Microsoft Excel.
- Parallel Capability: Connect additional SLB-Series units to increase total discharge current.
- Assistant Discharge Mode: Compatible with existing non-SLB load banks.
- Built-In Circuit Breakers: Overload protection and emergency shutdown capability.
- Optional DAC Package: Real-time per-cell voltage monitoring for 1.2V, 2V, 6V, and 12V cells (custom options available).
- Backlit LCD Display: Clear on-site visibility of test parameters and system status.
Specifications
| Nominal System Voltage: | 24/48 VDC |
| Discharge Current Range: | 12 – 200A (Single Unit) / Up to 1200A (Parallel with Additional SLB Units) |
| Discharge Voltage Range: | 10 – 576V (Max System Capable) |
| Voltage Steps: | 12V, 24V, 36V, 48V, 80V, 125V, 240V, 380V, 480V |
| Cell Voltage Monitoring (Optional DAC): | Standard: 1.2V, 2V, 6V, 12V / Optional: 3.6V, 4V, Custom Configurations Available |
| Accuracy: | Discharge Current: ±1% / Voltage: 0.5% – 0.8% |
| Resolution: | Current: 0.1A or 0.5% / Voltage: 0.001V |
| Sampling Interval: | 5 Seconds – 1 Minute |
| Data Transfer: | USB, Wireless (466 MHz) |
| Display: | Backlit LCD |
| Operating Environment: | 0 – 40 °C (32 – 104 °F) |
| Power Requirements: | 110/220 VAC 50/60 Hz or DC (From Connected Battery) |
| Dimensions: | Varies by Enclosure Size (Small through XX-Large) |
| Weight: | Varies by Enclosure Size (24 – 122 lbs) |
Resources & Support
Product Literature
Support Documents
Downloads
Videos
FAQs
Why is discharge testing necessary?
Discharge testing is the most verifiable method to confirm accurate battery capacity and ensure the system can support required loads during an outage.
Is the SLB-24/48-200 suitable for NERC compliance testing?
Yes. The programmable constant-current discharge and DataView reporting capabilities support documentation requirements for NERC-related maintenance programs.
Can I increase discharge current beyond 200A?
Yes. The SLB-24/48-200 can be paralleled with another SLB-Series unit to increase total discharge current capacity.
Does this unit support individual cell monitoring?
Yes. With the optional DAC package, real-time monitoring of individual cell voltages is available for multiple cell configurations.
Can the SLB-24/48-200 work with my existing load bank?
Yes. The Assistant Discharge feature allows it to operate alongside existing non-SLB load banks, adding monitoring capability and increasing current capacity.
What industries commonly use this model?
The SLB-24/48-200 is commonly used in utility substations, telecom facilities, data centers, and industrial DC power applications.
